BLADE T400
OSP
OSP
Characteristics
| Foil |
 |
| Application |
Model variations
| 5720 VMC(5AX)1 Table(C) 1+1 MillSpindle(B)+MovingColumn |
| Category | Item | Specification |
| Capacity | Distance between spindle and tailstock | 1500 |
| Workpiece | Workpiece diameter[mm] | 400 |
| Workpiece length[mm] | 1500 | |
| Travels | Stroke X[mm] | 1860 |
| Stroke Y[mm] | 400 | |
| Stroke Z[mm] | 450 | |
| Stroke A[deg] | 360 | |
| Stroke B[deg] | 140(-50~90) | |
| Rapid traverse(X)[m/min] | 40 | |
| Rapid traverse(Y)[m/min] | 40 | |
| Rapid traverse(Z)[m/min] | 40 | |
| Rapid traverse(A)[r/min] | 200 | |
| Rapid traverse(B)[r/min] | 25 | |
| Category | CNC brand | OSP |
| CNC system | OSP-P300MA | |
| Origin | Japan |
Milling spindle 1(H1)
| Spindle name | H1-1 | Taper | HSK-A63 | Rotational speed[rpm] | 18000 | Power[kW] | 28(Cont)!38(30min) | Torque[Nm] | 114(Cont)!146(10min)!198(3min) | Transmission |
Tool Magazine 1
| Tool holder taper | HSK-A63 | No. of tool storage[ea] | 40 60 80 | Tool diameter[mm] | 90(A)!130(B) | Tool length[mm] | 250 | Tool weight[kg] | 8 | Tool change time(TTT)[s] | Tool change time(CTC)[s] |
*A: Max. tool diameter (with adjacent tools)*B: Max. tool diameter (without adjacent tools), C: Max. tool diameter (single point)
Photo gallery
Not responsible for misprints or data errors. Actual product appearance may differ.
